VP Solar has renewed, for the year 2021, its proposal of storage systems for photovoltaic systems, updating it with the new DC and AC systems recently introduced on the market.
The range of products in the price list covers many installation conditions, proposing main brands’ solutions. This allows us to satisfy the requests of each customer with high levels of quality and safety.
AC and DC side solutions
The storage of energy produced by photovoltaic systems has long been a viable solution to improve self-consumption levels, thus also raising savings in the bill.
The devices can be divided into three parts:
- AC side storage
- DC side storage with connection on MPPT channels
- DC side storage with connection to hybrid inverters
In the first case, VP Solar offers various solutions that can be adapted to any single-phase or three-phase string inverter. These devices are the most used on existing systems.
The second type of storage, on the other hand, concerns a particular solution that allows reaching a quantity of kWh, which can be connected to a single MPPT, equal to 12.
Connection to hybrid inverters is probably the most suitable solution in newly built systems, where you want to combine photovoltaic storage from the very beginning.
These inverters can reach sizes up to 10 kW, but in some cases, they can be expanded up to even 100 kW of the plants. On each inverter, it is possible to reach up to 30 kWh of storage.
Storage Guide and Storage Map 2021
VP Solar offers various tools to find the best solution for your needs.
In addition to the publication of the Storage 2020 Guide, the new Storage Map has been updated in the 2021 version: a comparative table divided into brands that show several interesting features of the storage system, including:
- Compatible batteries
- Back-up function
- Available sizes
- Expandability of the system
Download the Storage MAP: storage systems comparative table
- 12 manufacturers of photovoltaic storage systems
- Matching inverters and batteries
- All the combinations available
- Type of system: hybrid or AC connection
- Type of network: three-phase or single-phase
- Product warranty: years and % of remaining capacity
- All data on power and storage capacity
-
BYD, Storage Battery
BYD: Battery-Box Premium HVS / HVM – high voltage – from 5.1 to 66.2 kWh
The new high voltage batteries of the BYD brand are devices compatible with many single-phase and three-phase inverter brands.
BATTERY-BOX PREMIUM HVS
- composed of 2 to 5 HVS battery modules
- capacity of 5.1 to 12.8 kWh
BATTERY-BOX PREMIUM HVM
- composed of 3 to 8 HVM battery modules
- capacity of 8.3 to 22.1 kWh
SKU: n/a -
BYD, Storage Battery
BYD: Battery-Box Premium LVS – low voltage – from 3.8 kWh to 245.8 kWh
BYD Battery-Box Premium LVS low voltage battery (48V) to be combined with various three-phase and single-phase inverters.
- Scalable from 4 kWh to 246 kWh
- Maximum Flexibility for any application with up to 64 Modules connected in parallel
- Capable of High-Powered Emergency-Backup and Off-Grid Function
- Patented Internal Plug Design Requires No Additional Wiring
SKU: n/a -
GoodWe, Storage Battery
GoodWe Lynx Home U – low voltage – from 5.4 kWh to 32.4 kWh
GoodWe’s Lynx Home U Series lithium batteries are low voltage batteries designed for residential applications.
- Nominal voltage of 51.2V
- Compatible with GW xx00 S-BP, GW xx48-EM
- 10 Years warranty
- Available sizes: 5.4 / 10.8 / 16.2 / 21.6 / 27 / 32.4 kWh;
SKU: n/a -
Huawei, Storage Battery
Huawei LUNA2000 – smart string battery – 5/10/15 kWh
Lithium batteries for photovoltaic storage. Modular system with 5 kWh stackable battery packs with 100% discharge capacity.
- Modular design of 5kWh, 10 kWh and 15 kWh and parallelable up to 2 systems for a total of 30 kWh
- 10 year guarantee
- Configurable with Huawei Hybrid Single and Three Phase Inverters
SKU: n/a -
Huawei, Storage Battery
Huawei LUNA2000-7/14/21-S1
Storage system with 6.9 kWh LFP cells, modular solution with the possibility of stacking up to three battery packs per tower with a maximum capacity of 20.7 kWh parallelable up to 4 towers for a total of 82.8 kWh.
Huawei inverter compatible batteries:
- SUN2000-12/15/17/20/25K-MB0
- SUN2000-3/4/5/6/8/10KTL-M1
- SUN2000-2/3/3.68/4/4.6/5/6KTL-L1
SKU: n/a -
Jinko Solar, Storage Battery
Jinko Solar: Sungiga – all-in-one cabinet for C&I applications
The Sungiga JKS-215KLAA-100PLAA is an all-in-one energy storage solution which packs battery modules, BMS, PCS, fire suppression systems and liquid cooling in a single cabinet.
- Capacity: 215 kWh
- Charge/discharge power: 100 kW
- Liquid cooling
- Integrated fire suppression system
- IP 55
- Cloud-based monitoring
SKU: n/a -
LG Energy Solution, Storage Battery
LG Energy Solution PRIME – high voltage – 10H/16H
LG PRIME offers maximum safety for electricity consumption regardless of external uncertainties, achieving energy independence through the conservation of self-produced and eco-friendly solar energy.
- It works in temperatures ranging from -10°C to 50°C, so it is suitable for any type of weather conditions.
- The installation can be done both on the wall and on the floor.
- Available sizes: PRIME 10H, PRIME 16H.
SKU: n/a -
LG Energy Solution, Storage Battery
LG Energy Solution RESU – low voltage – 6.5/10/12
LG Energy Solution with RESU battery packs 48 V provides the most advanced solution in the market with regard to lithium-ion view the best energy density, high quality and reliability.
Three levels of basic skills from 6.5 kWh, 9.8 kWh and 13.1 kWh with expandability up to 26,2 kWh.
- Compact size and easy installation
- Better energy density in the world
- Tested safety
SKU: n/a -
LG Energy Solution, Storage Battery
LG Energy Solution RESU – high voltage – 10M
High-voltage residential battery with modular design consisting of two battery modules and a BPU (Battery Protection Unit), which make it extremely handy and easy to install.
- battery module weight 36Kg, total weight with all three parts combined 80 kg
- extremely small size: base 45cm x height 51cm and 24cm deep
- compatible with Sunny Boy Storage 3.7 inverters
- RESU10M energy 9.8 kWh
SKU: n/a -
Pylontech, Storage Battery
Pylontech H48050A lithium battery HIGH voltage
The Pylontech H48050A lithium battery is the module that connected in series allows to obtain storage systems with different types of working voltages and storage capacity, depending on the application. The system consists of a control module and several battery modules.
- 4.8 kWh energy for single-phase systems and 9.6 kWh for three-phase systems
SKU: n/a -
Pylontech, Storage Battery
Pylontech RACK CABINETS
Pylontech Rack cabinets painted with polyester powder, suitable for Pylontech batteries.
- Single section cabinet painted in polyester powder, embossed finish with ventilation grilles in RAL 5011 and RAL 5021
- Adjustable feet kit for wardrobe
- Pylontech / inverter connection cables kit
- Back brackets for battery support included for cabinets from 9U to 42U
SKU: n/a -
Pylontech, Storage Battery
Pylontech US2000 lithium battery
The Pylontech US2000 lithium battery module is suitable for making small and medium capacity storage systems.
- From 2.4 kWh
- Up to 16 units without parallel module.
- Modular to create storage systems even of large dimensions.
- Soft-start mode: reduces the peak current when the inverter has to start with only one battery.
SKU: n/a -
Pylontech, Storage Battery
Pylontech US3000 – lithium technology – low voltage
Pylontech US3000 lithium batteries, 3.55 kWh modules, maximum instantaneous charge and discharge power and depth of discharge up to 95%.
- 10 year warranty
- Longer life cycle, exceeding 6000 cycles
- Internal molecular structure of LFP batteries
- Compact and modular design
- Soft-start mode : reduces the peak current when the inverter must start with only one battery
SKU: n/a -
SolarEdge, Storage Battery
SolarEdge Energy Bank – high voltage – 10 kWh
Photovoltaic energy storage batteries with Li-ion NMC technology, nominal capacity of 10.3 kWh (100% DOD, effective capacity of 9.7 kWh).
- NMC 9.7kWh / 5kW Li-ion technology
- Support up to 3 batteries per inverter for more power and capacity 100% depth of discharge
- 10 year guarantee
SKU: n/a -
-
Storage Battery, Sungrow
Sungrow SBR – high voltage – from 9.6 to 102 kWh
High voltage lithium iron phosphate LFP batteries, modular and expandable at any time, with 10 years warranty and parallelable up to 4 units.
- They can charge and discharge with a maximum current of 30A
- Equipped with a charge status indicator
- IP55, can be installed both indoors and outdoors
- Protection from abnormal voltages and currents
- Available: SBR096 / SBR128 / SBR160/ SBR192 / SBR224 / SBR256
SKU: n/a -
Other, Storage Battery, ZCS Azzurro
ZCS Azzurro: battery H48050 – high voltage – from 2,1 to 51,8 kWh
Other, Storage Battery, ZCS AzzurroZCS Azzurro: battery H48050 – high voltage – from 2,1 to 51,8 kWh
The H48050 batteries are 2.4 kWh modules that can be used with the ZCS three-phase hybrid inverters, in combination with the SC500-H or SC1000-H BMS.
- LFP technology
- Total net capacity (single module): 2,4 kWh
- Maximum charge and discharge current: 25 A
- Module weight: 24 kg
- 10-year warranty
SKU: n/a -
Storage Battery, ZCS Azzurro
ZCS Azzurro: HV ZBT 5K – high voltage – from 5.12 kWh to 20.48 kWh
The high voltage batteries of the HV ZBT 5K series constitute a stackable system compatible with the ZCS three-phase hybrid inverters and the EasyPower all-in-one single-phase system.
- LFP batteries
- Nominal capacity (single module): 5,12 kWh
- Stackable system (up to 4 modules in parallel)
- Nominal voltage: 400 V
- Weight (single module): 50kg
- Warranty: 10 years
SKU: n/a -
Storage Battery, ZCS Azzurro
ZCS Azzurro: LV ZSX5000 PRO battery – low voltage – from 4,6 to 18,4 kWh
Storage Battery, ZCS AzzurroZCS Azzurro: LV ZSX5000 PRO battery – low voltage – from 4,6 to 18,4 kWh
The ZSX5000 PRO LV battery modules are an energy storage unit for residential applications, combined with ZCS single-phase inverters.
- LFP technology
- Total net capacity (single module): 4,6 kWh
- Nominal voltage (single module): 51,2 V
- Maximum charge and discharge current: 100 A
- 10-year warranty
SKU: n/a -
Storage Battery, ZCS Azzurro
ZCS Azzurro: Power Magic – all-in-one cabinet for C&I applications
The outdoor retrofit Power Magic storage system is ideal for large-scale industrial installations. It can be adapted to the needs of each customer and installation is simple, thanks to the plug & play design.
- Capacity: 215 – 258 kWh
- Charge/discharge power: 125 kW
- Liquid cooling
- Integrated fire suppression system
- IP55
- Integrated EMS and monitoring
SKU: n/a
