TSC Power home is the European division of an American company www.solaria.com leader in the production of Pure Black modules. The company boasts over 20 years of experience in the photovoltaic sector and has filed over 350 patents.
TSC modules: a winning technology
TSC photovoltaic panels, in addition to having an elegant design thanks to a pure black appearance, are certainly among the most powerful and perfoming modules on the market thanks to the innovative Power Xt technology.
This technology, by eliminating the interconnections between the cells and the bus bars, ensures that the amount of energy produced is greater.
This is also made possible by the different arrangement of the cells: the substrings are, in fact, connected in parallel within the 4 quadrants that make up the module, also reducing energy losses.
TSC modules thus achieve a proven efficiency of over 20% compared to other modules on the market. This technology also involves lower installation costs.
TSC modules have also obtained PID resistance certifications.
TSC product range
Among the range of modules available, modules of the PowerXT R-PD series and the PowerXT R-PM series are proposed.
PowerXT R-PD
- Power Range: 365WP
- Pure Black
- Suitable for commercial and residential installations (they can, in fact, be installed both vertically and horizontally)
- Dimensions: 1621mm x 1116mm x 40mm weight 21 kg
- PID resistance certification
- Guaranteed up to 25 years
PowerXT R-PM
- Power Range: 400 WP
- Pure black
- Suitable for commercial and residential installations (they can, in fact, be installed both vertically and horizontally)
- Dimensions: 1644mm x 1204mm x 40mm weight 21 kg
- PID resistance certification
- Guaranteed up to 25 years
TSC PowerXT R-PM – mono – black – 400 Wp
Totally black photovoltaic module (Pure Black) with more than 20% efficiency thanks to the exclusive PowerXT technology where bus-bars and multiple interconnections have been eliminated.
- PowerXT technology
- Pure Black
- 30 years full warranty
- Available: 400 Wp
Datasheet English
Fiche technique Français
Datenblatt Deutsch
Ficha de datos Español
Complete documentation
Achieving over 20% efficiency, TSC PowerXT solar panels are one of the highest power panels in the residential and commercial market.
Compared to traditional panels, PowerXT panels have fewer gaps between the solar cells and are manufactured with black backsheet and frames, giving them a striking appearance and higher efficiency.
Developed in America, TSC’s patented cell cutting creates a highly reliable PowerXT cell where busbars and ribbon interconnections, common failure points, are eliminated.
TSC’s patented panel assembly then packages the cells into the PowerXT solar panel, reducing inactive space between the cells. This process leads to an exceptionally attractive and efficient solar panel.
Higher Efficiency, Higher Power
TSC PowerXT panels achieve over 20% efficiency; traditional panels achieve 15% – 17% efficiency. TSC PowerXT panels are one of the highest power panels available.
Lower System Costs
PowerXT panels produce more power per square meter area. This reduces installation costs due to fewer balance of system components such as racking and cables.
Improved Shading Tolerance
Solar cell sub-strings are interconnected in parallel, within each of the four module quadrants, which dramatically lowers the shading losses and boosts energy yield.
Improved Aesthetics
Compared to traditional panels, PowerXT panels have a more uniform appearance and superior aesthetics, with a pure black photovoltaic panel.
Durability and Reliability
Solder-less cell interconnections are highly reliable and designed to exceed the industry leading product and power warranty of 30 years.
PID Resistant
PowerXT panels are PID resistant. This insures stable and predictable energy production over time.
