Hyundai HJT : latest generation modules

Hyundai has introduced the latest HeteroMaxTM Premium N-Type HJT (Hetero Junction Technology Solar Cell) photovoltaic modules in its range, which utilises SHINGLED technology for cell assembly.

Hyundai HJT is a high-efficiency (23.04%) bifacial and monocrystalline module: the cells have excellent light absorption with improved performance even in low irradiation situations.

Advantages compared to TOPCon technology:

  • Smaller dimensions 1722x1134x30: for the same yield, the area saved is around 2.2%.
  • Up to 30% increase in solar cell efficiency due to excellent light absorption
  • The temperature coefficient for power is extremely low (-0.26%): this allows high output to be maintained even as the temperature rises

Double-glazed design

HeteroMaxTM features a tempered double-glazed design to prevent corrosion of the inner material, and a reinforced frame. The bifacial structure with HJT technology leads to a much higher bifaciality coefficient, generating 2%/4% more power than PERC cells.

Guaranteed durability and reliability

Hyundai HJT is a long-lasting, high-performance product with a linear performance guarantee of 30 years (it has a degradation rate of about 1% in the first year, reaching a minimum producibility of 88% at year 30)

LID (Light Induced Degradation) and PID (Potential Induced Degradation) are strictly eliminated to ensure a higher yield over the life of the module

,

Hyundai HiT-HxxxOF-BF – HJT – 108 cells – 440 Wp


Hyundai HiT-HxxxOF-BF is a 108-cell monocrystalline bifacial photovoltaic module

  • 30 year product warranty, 30 year linear performance warranty
  • Maximum efficiency 23.04%.
  • Available size: 440 Wp

HeteroMaxTM Premium N-Type HJT utilises SHINGLED technology for cell assembly and features excellent light absorption with improved performance even in low irradiance situations.

Equipped with double front tempered glass and a reinforced black frame, the bifacial structure with HJT technology leads to a much higher bifaciality coefficient, generating 2% / 4% more power than PERC cells.

This module comes with MC4-EVO2 connector.

Wind and snow resistance

Hyundai HeteroMaxTM can withstand up to 5400 Pa snow load and 2400 Pa wind load

Warranty

Founded in 1972, the Hyundai Heavy Industries Group is one of the most trusted names in the photovoltaic industry. It offers a 30-year linear performance warranty

During the first year, the drop in performance will not exceed 1%, while by year 30, module output is guaranteed to be 88%.
