Solis S5-GR3P 4/20 K

Three-phase inverter from 3 to 20 kW Solis S5-GR3P(4-20)K, for small commercial and residential installations.

  • 2 MPPT
  • IP66
  • Communication: RS485, Optional: Wi-Fi, GPRS
  • MC4 connector
  • LCD Display
  • Available size: S5-GR3P4K, S5-GR3P5K, S5-GR3P6K, S5-GR3P8K, S5-GR3P10K, S5-GR3P20K

Three-phase inverter designed for small C&I and residential PV systems, available in sizes from 3 to 20 kW are compatible with high-efficiency and double-sided modules.

Maximum input current per string is 16A and voltage 1100 V.

Reduced fire risk due to integrated AFCI function, IP 66 protection rating, and automatic voltage stabilization technology in case of poor grid conditions.

Remote controls and upgrades supported and managed by the SolisCloud.
