Discover Sigenergy SigenStor and Sigen Hybrid, complete solutions for intelligent energy management in residential and small commercial settings.
The combination of modular storage systems and hybrid inverters offers an excellent solution to maximize self-consumption and promote efficient use of solar energy.
SigenStor storage system
At the core of Sigenergy’s residential offering is the SigenStor storage system, composed of stackable battery modules of 6 kWh and 9 kWh. This modular design allows the system to be configured flexibly and adapted to the specific energy needs of each household.
SigenStor batteries can be expanded at a later stage thanks to their architecture with integrated optimizers in each battery module.
The battery modules feature built-in plug-in connectors, simplifying and speeding up the installation process.
Sigenergy residential inverters
SigenStor EC inverters
The SigenStor EC hybrid inverters complete Sigenergy’s residential portfolio, integrating seamlessly with SigenStor batteries to form a compact, all-in-one system with a unified design.
They are available in single-phase versions from 3 to 6 kW and three-phase versions from 5 to 30 kW; up to 20 units can be connected in parallel for a single installation.
One of the most interesting features of the SigenStor EC line is the option to add a DC electric vehicle charging module, connected directly to the storage system. This module, equipped with a CCS2 cable, is prepared for bidirectional operation (V2X) and can manage up to 25 kW of charging or discharging power.
Sigen Hybrid inverters
Sigen Hybrid inverters offer another flexible and high-performance solution within Sigenergy’s residential range.
Available in single-phase versions from 3 to 6 kW and three-phase versions from 3 to 12 kW, these inverters can be paired with SigenStor batteries to create a complete energy management system.
They feature an ultra-slim design (just 99 mm) and do not need to be installed on top of the storage system.
Sigen Energy Gateway backup panels
Thanks to these panels, the SigenStor EC and Sigen Hybrid inverters can supply backup power to priority loads in the event of grid disconnection, with an ultra-fast switching time (as low as 0 ms).
They also allow integration with a generator to support loads during prolonged blackouts.
The panels are available in various versions:
-
HomePro SP (single-phase): max 1 inverter
-
HomePro TP (three-phase): max 1 inverter
-
HomeMax TP (three-phase): max 2 inverters, up to 50 kW
-
Gateway Cxxx: commercial gateways for applications with multiple SigenStor EC units
-
Hybrid inverter, Inverter, Photovoltaic inverter, Residential inverter Sigenergy, Sigenergy, Sigenergy
Sigenergy Sigen Hybrid 3.0/4.0/4.6/5.0/6.0 SP2 – single-phase
Hybrid inverter, Inverter, Photovoltaic inverter, Residential inverter Sigenergy, Sigenergy, SigenergySigenergy Sigen Hybrid 3.0/4.0/4.6/5.0/6.0 SP2 – single-phase
Sigenergy Sigen Hybrid SP2, high efficiency inverter for single-phase applications, with a 10 years warranty and the backup function potentially available.
- 2 MPP Tracker
- Backup through Gateway HomePro SP
- Wall-mounted
- Light (slightly heavier than 10kg)
- Available: 3.0SP2, 4.0SP2, 4.6SP2, 5.0SP2, 6.0SP2
SKU: n/a -
Hybrid inverter, Inverter, Photovoltaic inverter, Residential inverter Sigenergy, Sigenergy, Sigenergy
Sigenergy Sigen Hybrid 3.0/4.0/5.0/6.0/8.0/10.0/12.0 TP2 – three-phase
Hybrid inverter, Inverter, Photovoltaic inverter, Residential inverter Sigenergy, Sigenergy, SigenergySigenergy Sigen Hybrid 3.0/4.0/5.0/6.0/8.0/10.0/12.0 TP2 – three-phase
Sigenergy Sigen Hybrid TP2 three-phase hybrid inverter for residential and commercial applications with a 10 years warranty. It guarantees for three-phases systems the maximum self-consumption of energy thanks to its high performances.
- 2 MPPT
- Efficiency up to 99%
- IP66
- Backup available with Gateway Sigenergy HomePro TP
- Available: 3.0TP2, 4.0TP2, 5.0TP2, 6.0TP2, 8.0TP2, 10.0TP2, 12.0TP2
SKU: n/a
