Steca Solarix PLI 2400-24 / 5000-48 / 1000-12

Steca

With these features the Solarix PLI can be used in 3 modes:

  • off-grid system where the only source of energy are the photovoltaic modules
  • off-grid  system with backup with the possibility of choosing the priority source (photovoltaic or external)
  • UPS where the batteries are charged only from the mains grid and remain in buffer until the blackout.
  • Size available: 2400-24 / 5000-48 / 1000-12

The first all-in-one product from Steca Elektronik. The products of the Solarix PLI 2400-24, 5000-48 and 1000-12 series are composed of a 230V AC pure sine wave inverter, a photovoltaic charge controller with 40A or 80 A MPPT technology and a maximum voltage of 100 V or 145 V, an battery charger input 230 V AC for an external backup source as a power supply or a generator that can be activated via a relay. This allows you to create a complete island hybrid system.

Switching between battery power and external grid / generator is very fast, switching time shorter than 10 ms.

Through an accessory communication card, up to 9 machines can be inserted in the same system, thus forming a three-phase system with 3 machines in parallel for each phase, but also up to 9 machines on the same phase.

The Solarix PLI 5000-48 also supports unbalanced three-phase configurations, the important thing is not to exceed nine machines per plant.

Given the capacity of double overload with respect to the nominal power and the pure sine wave, any type of load can be powered.

The refined software of the search for the maximum power point always ensures the maximum charge of the batteries in any environmental condition.

The large display allows you to monitor all operating parameters comfortably, all settings are made directly from the display via the 4 function buttons, and the RS232 and USB communication ports are also available for connection to a PC.

Types of three-phase connections possible

Through an accessory communication card, up to 9 machines can be inserted in the same system, thus forming a three-phase system with 3 machines in parallel for each phase, but also up to 9 machines on the same phase.
It also supports unbalanced three-phase configurations.

Efficient software

The refined software of the search for the maximum power point always ensures the maximum charge of the batteries in any environmental condition.

Functional display

The large display allows you to monitor all operating parameters comfortably, all settings are made directly from the display via the 4 function keys, and the RS232 and USB communication ports are also available for connection to a PC.

Product features

  • Product features
  • True sine wave voltage
  • High overload capacity
  • Integrated MPP tracker
  • Multistage charging technology
  • Monthly equalisation charge
  • Auxiliary contact for starting the generator
  • Adjustable cut-off voltages
  • Battery type: gel / liquid lead battery
  • Lightweight construction
  • Easy installation

Electronic protection functions

  • Overcharge protection
  • Reverse polarity protection of modules, for battery via fuse
  • Deep discharge protection
  • Short circuit protection of load and module
  • Reverse polarity protection by internal fuse
  • Reverse current protection at night
  • Overtemperature and overload protection
  • Acoustic alarm
  • PE connection

Displays

  • Graphical LCD display
  • 3 multi-coloured LEDs show operating states

Operation

  • Simple menu-driven operation
  • Programming by buttons

Interfaces

  • RS-232 serial interface to PC
  • Connection to PC via USB Opzioni

Options

  • Interconnectable in parallel or in three phases (extension module required)

Certificates

  • Compliant with European Standards (CE)
  • RoHS compliant
  • Manufactured according to ISO 9001 and ISO 14001

Accessories

  • PC software is enclosed
